BGP Protection - TTL Security Configuratoion Cisco, Juniper and Nokia

Hi Everyone,

In the blog, I am going to explain how TTL security is useful in BGP Session protection. Time to Live will be added to every packet and it will be reduced at each hop it transfers.

Consider someone who wants to hack your BGP session and will send the spoofed  BGP packets and try to negotiate with your BGP session. to avoid this kind of spoofing we use TTL Security

TTL security is a mechanism that evaluates the TTL value of incoming IP packets to ensure

that they have not been faked. The IP TTL value will be set to 255 by directly connected BGP

peers, making it impossible to relay spoof Internet protocol with TTL=255 through non

directly connected interfaces.

Cisco XR

router bgp 100
 neighbor-group ebgp
  ttl-security
 !
neighbor 192.168.1.1
  remote-as 100
  use neighbor-group ebgp
  address-family ipv4 unicast
  !
 !

Juniper

protocols {
    bgp {
        group nokia {
            type external;
            neighbor 192.168.0.1 {
                ttl <1-255>;
                peer-as 100;
                local-as 200;
            }

Nokia vSR

router bgp
 group "juniper"
                type external
                local-as 100
                ttl-security <1-255>
                neighbor 192.168.0.2
                    peer-as 200
                exit
            exit
